2.17
MAINTENANCE
2
Throttle Pedal Inspection
If the throttle pedal has excessive play due to cable stretch or
cable misadjustment, it will cause a delay in throttle response.
Also, the throttle may not open fully. If the throttle pedal has no
play, the throttle may be hard to control, and the idle speed may
be erratic.
Check the throttle pedal play periodically in accordance with the
Periodic Maintenance Chart and adjust if necessary.
Throttle Stop Speed Control
Use the following procedure to control how far the throttle
opens.
IMPORTANT: This procedure should be performed
by consumers only when they determine that their
child is capable of handling the additional speed.
1. Loosen the jam nut.
2. Turn the screw clockwise to increase speed or counter-
clockwise to reduce speed.
3. Tighten the jam nut after adjusting.
Jam Nut
Stop Screw
Decrease / Increase
SPEED
