Polaris SCRAMBLER 500 2000 User Manual

A12
ENGINE MOUNTING
Scrambler 500 A00BG50AA
Ref. Part No . Qty. Description Ref. Part No. Qty. Description
1 7547108 6 Nut, Flange
2 7555823 3 Washer, Flat
3 4010132 1 Cable, Ground/Engine
4 7512232 1 Screw
5 3110044 1 Mount, Rubber, Top
6 5242674-067 1 Bracket, Mount, Engine, Top
7 7552901 2 Washer, Spring Lock
8 7512315 2 Bolt
9 7080003 4 Clamp, Hose, Red
10 8450040-600 AR Line, Fuel
11 8450003-1525 AR Line, Fuel
12 3084205 3 Screw and Washer
13 3110032 2 Mount, Radiator
14 5242258-067 1 Br acket, Carburetor Mount
15 7552605 2 Washer, Split Lock
16 7542105 2 Nut
17 -- -- -- -- -- -- -- 1 Asm., Carburetor
(See Carburetor Pg. D10, Ref. 18)
18 8360009-600 AR Line, Fuel
19 8450080-58 1 Sheath, Foil, Laminated
20 1012883-067 1 Mount, Rear Motor
21 7547089 2 Nut, Flange, Lock
22 3110046 2 Mount, Rubber
23 7517289 1 Screw
24 7555815 2 Washer
25 5410421 1 Boot, Clutch Intake
26 7080511 1 Clamp, Narrow Band
27 5430261 1 Bushing
28 5210748 1 Washer, Flat
29 7575202 1 Washer, Interlock
30 7512566 1 Bolt
31 -- -- -- -- -- -- -- 1 Asm., Drive Clutch, ATV-06
(See Drive Clutch Pg. B14, Ref. 14)
32 -- -- -- -- -- -- -- 1 Bracket, Retainer, Seal
(See Clutch Cover Pg. C8, Ref. 21)
33 1040688-067 1 Mount, Engine
34 7515398 2 Screw
35 7542324 2 Nut, Nylok
36 3110067 1 Mount, Rubber
37 7080474 2 Clamp
38 7552603 1 Washer, Spring Lock
39 7515438 1 Screw
40 7080696 2 Clamp
41 -- -- -- -- -- -- -- AR Hose, Engine, Lower (See Cooling
System Pg. A9, Ref. 12)
42 -- -- -- -- -- -- -- 2 Nut (See Cylinder Pg. D6, Ref. 23)
43 -- -- -- -- -- -- -- 2 Washer, Lock
(See Cylinder Pg. D6, Ref. 22)
44 1260994-029 1 Manifold, Black
45 -- -- -- -- -- -- -- 1 Gasket, Exhaust
(See Cylinder Pg. D6, Ref. 20)
46 3085822 1 Engine, Short Block (EH50PLE04)
NOTE: The Short Block assembly
contains a crankcase assembly, cylin-
der and cylinder head assembly, and a
piston & crankshaft assembly. Prior
authorization required for warranty
consideration.
47 -- -- -- -- -- -- -- AR Hose, Engine, Upper (See Cooling
System Pg. A9, Ref. 13)
9/99
