D6
CYLINDER
Scrambler 500 A00BG50AA
Ref. Part No . Qty. Description Ref. Part No. Qty. Description
1 3084045 1 Asm., Band, Adapter (Incl. 2)
2 3081497 1 Screw
3 3081330 2 Bolt
4 3084857 2 Pin, Straight
5 3084994 4 Guide, Valve
6 3084858 2 Seal, Intake Valve
7 3084867 1 O-Ring
8 3085072 1 Adapter, Water Out
9 3084877 10 Bolt, Flange
10 3084866 1 Adapter, Camshaft
11 3085074 1 Gasket, Rocker Cover
12 3085073 1 Cover, Rocker
13 3084874 10 Bolt, Flange
14 3084859 2 Seal, Exhaust Valve
15 3084875 4 Bolt, Cylinder Head
16 3084860 1 Plug
17 3084861 1 Gasket
18 3084862 1 Plug, Blind
19
3084215 2 Bolt, Flange
20 3085075 1 Gasket, Exhaust
21 3085326 2 Stud
22 3080530 2 Washer, Lock
23 3080285 2 Nut
24 3085854 1 Bolt, Rocker Shaft
25 3084876 4 Bolt
26 3084864 1 Support, Valve Rocker Shaft (PTO)
27 3084863 1 Support, Valve Rocker Shaft (MAG)
28 3084838 2 Pin, Straight
29 3084849 1 Union, Oil Pump
30 3084873 4 Bolt, Flange
31 3086811 1 Cylinder (Incl. 32)
32 3084130 1 Pipe 2, Elbow
33 3085370 1 Gasket, Cylinder
34 3084868 1 Cover, Camshaft
35 3086200 1 Gasket, Cover, Cam
36 3085527 1 Head, Cylinder (Incl. 4-6,14,16-18,21)
37 3085371 1 Gasket, Head
38 3085809 1 Adapter
5/99
