B12
CONTROLS - THROTTLE ASM./CABLE
Scrambler 500 A00BG50AA
3
1
5
4
6
2
Ref. Part No . Qty. Description Ref. Part No. Qty. Description
1 5433806 1 Cover , Throttle Control
2 5410193 1 O-Ring
3 5411439 1 O-Ring
4 7080709 1 Cable, Throttle Control
5 2010188 1 Asm., Throttle Control (Incl.1,3,6)
6 2010191 1 Asm., Throttle Clamp
3/00
