Polaroid 600SE

31
Removing Hand Grip Flash Shoe (Model 600SE) (Figure 4-3)
a. Remove stopper screw.
b. Remove shoe cover.
c. Remove the four (4) screws holding the shoe and the cable release rack.
Figure 4-3. Removing hand grip flash shoe and cable release rack (model 600SE)
Stopper Screw
Shoe Cover
Screws (4)
Hand Grip
Flash Shoe
Cable Release
Rack
Hand Grip
