Polaroid 600SE

34
Releasing Screw from Holder Plate (Figure 4-7)
Lay camera on a soft surface, with viewfinder windows facing up. Remove Phillips head screw
shown in Figure 4-7.
Figure 4-7. Removing holder plate screw from viewfinder window
Removing Top Cover (Figure 4-8)
Complete part removal shown in Figures 4-5 through 4-7. Remove three (3) Phillips head screws
and three plastic washers holding cover to camera body. Lift and remove top cover.
Figure 4-8. Removing viewfinder cover
Holder Plate Screw
Cover
