Polaroid 600SE

33
Removing Rangefinder Covers (Figures 4-5 through 4-8)
The rangefinder/viewfinder can be removed from model 600 and 600SE cameras without remov-
ing any other major assembly. The viewfinder window cover and the top cover can be removed to
allow inspection and adjustment.
On the model 600SE camera, move the viewfinder indicator to the 150 position to give access to
an anchor screw securing the rangefinder assembly to the camera body. Remove screw and
button shown in Figure 4-5.
Figure 4-5. Removing viewfinder selector switch
Removing Viewfinder Window Cover (Figure 4-6)
The viewfinder window cover can be removed for inspection, cleaning and repair of viewfinder
windows. Remove two (2) screws (Phillips head) holding viewfinder window cover to camera front
panel.
Figure 4-6. Removing viewfinder window cover
Viewfinder Indicator
Viewfinder Selector Switch
Screw and Button
Camera
Front Panel
Screws
Viewfinder Window
Cover
