9
Figure 1-2. Location of the rangefinder assembly
Differences Between Models
A summary of the differences between the two models is contained in Table 1-1. The basic
camera is 7" high, 7" deep and 9" wide (18cm X 18cm X 18cm X 24cm) (including hand grip).
The weight including the pack film holder is about five pounds (2.2 kg). Additional weight
information is included in Table 1-1.
Camera Features
These professional pack film cameras have the following features, most of which are identified
in Figure 1-3 and Figure 1-4.
Carrying Straps - Strap eyelets are provided on the body of the camera to allow the
addition of a neck strap. An adjustable had strap is provided on
the hand grip.
Tripod Socket - The bottom of the camera body has a socket which accepts a
1/4-20screw, for mounting the camera onto a tripod.
Top Cover
Rangefinder Assembly
Camera Body
Face Plate
RF/VF Window Cover
