Polaroid 600SE

48
Figure 4-31. Removing 127mm lens assembly from model 600 camera
Figure 4-32. Removing springs from bayonet
Model 600 Camera
Red Line on Depth of
Field Scale (in Twelve
O'Clock Position)
Washer (3)
127MM Lens Assembly
Screws (6)
Model 600SE Camera
Spring (4)
Heel End of Spring
Spring Slot (4)
Bayonet
Screw (8)
