Polaroid 600SE Repair Manual

8
1- Description
General
The Polaroid Land Models 600 and 600SE Professional Pack Film Cameras are non-folding
cameras designed for the professional photographer. They use a removable Polaroid pack film
holder which accommodates Polaroid pack film holder which accommodates Polaroid type
100/600 Land Film.
Major Assemblies of the Camera
Each camera has three major assemblies (Figure 1-1). The camera body and handle, the lens-
shutter assembly and the film holder.
Figure 1-1. Major assemblies of the camera
The camera body with handle attached support the film holder and the lens-shutter assembly.
The camera body houses the rangefinder assembly as shown in Figure 1-2. The rangefinder
assembly has a built-in viewfinder. It is referred to as the RF/VF (rangefinder/viewfinder).
Film Holder
Camera Body
With Handle
Camera Body Cap
Lens Assembly

Polaroid 600SE Specifications

General

Lens Mount	Mamiya Press mount
Focus	Manual focus
Shutter	Leaf shutter in lens
Exposure Modes	Manual
Type	Rangefinder camera
Flash	PC sync socket
Shutter Speed	1 - 1/500 sec, Bulb
Weight	Approx. 1.6 kg (varies with lens)
