Polaroid 600SE

55
Reassemble by placing spring on parallax coupling lever assembly. The position of the levers
as you look up inside the camera is shown i the left side of Figure 4-41)
Removing Rang Lever Assembly (Figure 4-42)
Remove two (2) Phillips head screws from range lever upper. Carefully pull range lever upper off
the brass centering pin of the range lever assembly. Hold the range lever assembly inside the
body of the camera. Use screwdriver with a thin flat blade 1/2" (1.3 cm) long. Remove hub, range
lever assembly and washer.
Figure 4-42. Removing range lever assembly
Screws (2)
Range Lever
Upper
Camera Body
Washer
Range Lever
Assembly
