Polaroid 600SE

86
c. The aiming of the 75mm accessory viewfinder can be adjusted left or right by loosening the
screws securing the accessory shoe ( Figure 5-14). Shift position of accessory shoe.
Figure 5-14. Adjusting aiming of the 75mm accessory viewfinder
by repositioning accessory shoe
d. Up-and-down 75mm aiming can be adjusted two ways (Figure 5-15). First check that the
distance scale on the accessory viewfinder agrees with the measured distance to the
target. If in error, adjust distance scale to agree with measured distance. Use spanner
wrench with pencil point tips to loosen lock-screw.
Figure 5-15. Adjusting distance scale on 75mm accessory viewfinder
Stopper Screw
Shoe Cover
Screws (4)
Accessory Shoe
Cover
Holder Plate
Accessory Wide
Angle Viewfinder
Lock Screw
Distance Scale
