Polaroid 600SE

94
6 - Special Tools and Test Equipment
The special tools listed in Table 6-1 are used to repair the model 600/600SE cameras.
Table 6-1. Special Tools and Test Equipment
Name Tool Number
Collimator 11431
Focal Plane Plate CCR-12262
Reporter Aiming and ECR-12261
Framing Target
Aiming Circle ACR-12438
Spanner Wrench CCR-12459
Spreader for Mini-Roller 11606
Figure 6-1. Collimator and focal Plate
AC Power Cord
Plugs into
110 VAC Outlet
Infinity Tube
Collimator
Focal Plane
Plate
