Polaroid 600SE

58
Removing Strap Eyelets (Figure 4-46)
Use Phillips screwdriver to remove three (3) screws from each strap eyelet. Lift off strap
eyelet. Remove adhesive and clean parts before reassembly.
Figure 4-46. Removing strap eyelets
Removing Flash Gun Mounting Socket (Figure 4-47)
Use Phillips screwdriver to remove four screws holding flash gun mounting socket to camera
body.
Figure 4-47. Removing flash gun mounting socket
Screws
Strap
Eyelet
Flash Gun
Mounting Socket
Camera Body
Screws
