Page #126 background imageLoading...
Page #126 background image
SD300
POWER ELECTRONICS
124
DESCRIPTION OF PROGRAMMING PARAMETERS
Screen
Description
Default
value
Range
Function
Set
on
RUN
bA.34
Auto tuning
level for Ld
and Lq
33.3%
20.0 to 50.0%
Adjusts the autotuning level for Ld (active
energy axis) and Lq (reactive energy axis), for
the synchronous motors permanant magnet
motor control.
Note: Visible parameter if dr.9 = PM Sensor-
less
NO
bA.35
Frecuencia
de autoajuste
para Ld y Lq
100.0%
80.0150.0%
Adjusts the frequency of autotuning for Ld
(active energy axis) and Lq (reactive energy
axis), for the synchronous motors permanant
magnet motor control.
Note: Visible parameter if dr.9 = PM Sensor-
less
NO
bA.41
[4]
User
Frequency 1
1500Hz
0.00 to dr.20
Set user frequency 1. When the output
frequency reaches this value, the drive will
provide the voltage set in parameter bA.42.
NO
bA.42
[4]
User Voltage
1
25%
0 to 100%
Set user voltage 1. The drive will provide the
frequency set in parameter when the
frequency configured in bA.41 is reached.
NO
bA.43
[4]
User
Frequency 2
3000Hz
0.00 to dr.20
Set user frequency 2. When the output
frequency reaches this value, the drive will
provide the voltage set in parameter bA.44.
NO
bA.44
[4]
User Voltage
2
50%
0 to 100%
Set user voltage 2. The drive will provide the
frequency set in parameter when the
frequency configured in bA.43 is reached.
NO
bA.45
[4]
User
Frequency 3
4500Hz
0.00 to dr.20
Set user frequency 3. When the output
frequency reaches this value, the drive will
provide the voltage set in parameter bA.46.
NO
bA.46
[4]
User Voltage
3
75%
0 to 100%
Set user voltage 3. The drive will provide the
frequency set in parameter when the
frequency configured in bA.45 is reached.
NO
bA.47
[4]
User
Frequency 4
000Hz
0.00 to dr.20
Set user frequency 4. When the output
frequency reaches this value, the drive will
provide the voltage set in parameter bA.48.
NO
[
4
] These parameters will only be displayed if bA.7 or M2.25 are set to 2 (V/F Us).
