Power Electronics SD300 Series User Manual

SD300
POWER ELECTRONICS
126
DESCRIPTION OF PROGRAMMING PARAMETERS
Screen
Description
Default
value
Range
Function
Set
on
RUN
bA.56
[5]
Multi-
Reference7
6000%
DIGITAL
OUTPUT: Speed
MULTI
REFERENCE
PARAM.
H
M
L
0
0
X
Multi-reference
1
St1
0
X
0
Multi-reference
2
St2
0
X
X
Multi-reference
3
St3
X
0
0
Multi-reference
4
bA.53
X
0
X
Multi-reference
5
bA.54
X
X
0
Multi-reference
6
bA.55
X
X
X
Multi-reference
7
bA.56
Note: 0: Inactive and X: Active.
YES
bA.70
Acceleration
ramp 2
20.0s
0.0 to 600.0s
The user can set different acceleration and
deceleration ramps for the drive. In order to do
this, parameters bA.70-82 must be configured
and the acceleration and deceleration times
entered (parameters ACC and dEC from group
“Operation”).
The established setting within the parameter is
the time required to reach the maximum
frequency value, starting from 0Hz (or to
reduce the frequency according to the
deceleration times). These ramps will be set
according to the process necessities.
Note: continues on the next page.
YES
bA.71
Deceleration
ramp 2
30.0s
YES
bA.72
[6]
Acceleration
ramp 3
20.0s
YES
bA.73
[6]
Deceleration
ramp 3
30.0s
YES
bA.74
[6]
Acceleration
ramp 4
20.0s
YES
bA.75
[6]
Deceleration
ramp 4
30.0s
YES
bA.76
[6]
Acceleration
ramp 5
20.0s
YES
bA.77
[6]
Deceleration
ramp 5
30.0s
YES
[5] These parameters will only be displayed if one of In.65-ln71 is set to SPEED-L/M/H.
[
6
] These parameters will only be shown if one of parameters In.65-ln71 is set to
ACC/DEC-B/M/H.
