Installation and Operation Manual Page 71 of 104
(PVI-3.8/4.6-I-OUTD-US Rev.: 1.1)
E-da: Daily energy output.
$-da: Daily energy savings. The value is expressed in the set currency.
4A)
E-tot: Total energy output (since first installation)
E-par
:
Partial energy output during the period selected
by us
5A)
P-out: Measured instant output power
The second line of the display shows the higher of the two temperatures:
T-boost1: Booster channel 1 switching device temperature
T-boost2: Booster channel 2 switching device temperature
6A)
Ppk: Maximum peak power achieved since the 'partial' function was activated
Ppk-Day: Indicates the maximum peak power achieved during the day. The counter
will reset when unit is powered off.
7A)
Vgrid: Measured instant grid voltage
Vgrid Avg: Average grid voltage calculated over the last 10 minutes of inverter
operation
8A)
Igrid: Measured instant grid current
Fgrid: Measured instant grid frequency
Igrid 0.8 A
Fgrid 50.18 Hz
Vgrid 197 V
Vgrid Avg 0 V
Ppk W
