Installation and Operation Manual Page 72 of 104
(PVI-3.8/4.6-I-OUTD-US Rev.: 1.1)
9A)
Vin1: Instant input voltage value measured at channel 1 input
Iin1: Instant input current value measured at channel 1 input
10A)
Vin2: Instant input voltage value measured at channel 2 input
Iin2: instant input current value measured at channel 2 input
Or:
In a configuration with one input connected and a second input connected in parallel,
this screen is shown instead of the 2 screens previously described.
11A)
Pin1: Measured instant input power of channel 1
Pin2: Measured instant input power of channel 2
In a configuration with one input connected and a second input connected in parallel,
this screen is shown instead of the screens shown above.
12A)
Ileak: Value of the leakage current passing through the grounding fuse. This value is
only displayed in the case of the connected positive or negative terminal being
grounded.
Ileak 7 mA
Pin 0 W
Pin 1 0 W
