Installation and Operation Manual Page 96 of 104
(PVI-3.8/4.6-I-OUTD-US Rev.: 1.1)
36 Cell Panels 48 Cell Panels 72 Cell Panels
Panel Min. Temp. [°F]
Panel Voltage
Max. Number of
Panels
Panel Voltage
Max. Number of
Panels
Max. Number of
Panels
Panel Voltage
77 21.6 27 28.8 20 43.2 13
68 22.0 27 29.4 20 44.0 13
59 22.4 26 29.9 20 44.9 13
50 22.8 26 30.5 19 45.7 13
41 23.3 25 31.0 19 46.5 12
32 23.7 25 31.6 19 47.3 12
23 24.1 24 32.1 18 48.2 12
14 24.5 24 32.7 18 49.0 12
5 24.9 24 33.2 18 49.8 12
-4 25.3 23 33.8 17 50.7 11
-13 25.7 23 34.3 17 51.5 11
Table A
