Installation and Operation Manual Page 97 of 104
(PVI-3.8/4.6-I-OUTD-US Rev.: 1.1)
Description
Value
PVI-3.8-I-OUTD
Value
PVI-4.6-I-OUTD
Max. recommended
DC power input
4,420 W 5,260 W
Rated DC power input 4,000 W 4,840 W
Rated input voltage 330 Vdc 330 Vdc
Max. absolute input
voltage
520 Vdc 520 Vdc
Input voltage, MPPT
operating range
from 90 Vdc to 520
Vdc
from 90 Vdc to 520
Vdc
Input voltage, MPPT
operating range at full
power
from 200 Vdc to 470
Vdc
from 200 Vdc to 470
Vdc
Max. short circuit
current (of each array)
15.6 Adc 17 Adc
Max. operating input
current (of each array)
12.5 Adc 14 Adc
Max. input power (of
each array)
(1)
3,000 W 3,000 W
PV ground fault
connection
1A 600V fuse 1A 600V fuse
Input channel (array)
configuration
Parallel / Independent
(2)
Parallel / Independent
(2)
(1)
The total input power shall not exceed the max. recommended DC power
(2)
The configuration Independent is not available for –PG models
