Powtran PI9000 series User Manual

Chapter 5 Function parameter
102
51
Jog order
3
（ set
F7.54 ）
Jog running order，direction set through F7.54
Note: “Superscript
3
”means software version of C3.00 and above with MCU
keyboard have such function.
Table 1 Function description of multi-stage command
The 4 multi-stage command terminals can be combined as 16 status, these 16 status
have 16 command set values. As shown in Table 1:
K4
K3
K2
K1
Command setting
Parameters
OFF
OFF
OFF
OFF
0-stage speed
setting 0X
E1.00
OFF
OFF
OFF
ON
1-stage speed
setting 1X
E1.01
OFF
OFF
ON
OFF
2-stage speed
setting 2X
E1.02
OFF
OFF
ON
ON
3-stage speed
setting 3X
E1.03
OFF
ON
OFF
OFF
4-stage speed
setting 4X
E1.04
OFF
ON
OFF
ON
5-stage speed
setting 5X
E1.05
OFF
ON
ON
OFF
6-stage speed
setting 6X
E1.06
OFF
ON
ON
ON
7-stage speed
setting 7X
E1.07
ON
OFF
OFF
OFF
8-stage speed
setting 8X
E1.08
ON
OFF
OFF
ON
9-stage speed
setting 9X
E1.09
ON
OFF
ON
OFF
10-stage speed
setting 10X
E1.10
ON
OFF
ON
ON
11-stage speed
setting 11X
E1.11
ON
ON
OFF
OFF
12-stage speed
setting 12X
E1.12
ON
ON
OFF
ON
13-stage speed
setting 13X
E1.13
ON
ON
ON
OFF
14-stage speed
setting 14X
E1.14
