Chapter 5 Function parameter
113
arrival
(shutdown without
output)
frequency reaches the lower limit frequency
Outputs OFF signal when the inverter is in the
state of stop
Undervoltage status
output
Outputs ON signal when the inverter is in
the undervoltage condition
Please refer to communication protocol.
Zero speed running 2
(shutdown with output)
Outputs ON signal when the inverter
output frequency is 0. Outputs ON signal too
when the inverter is in the state of stop
Accumulated power-
on time arrival
Outputs ON signal when the inverter's
accumulated power-on time(F6.08) exceeds the
set time by F7.20.
Frequency level
detection FDT2 output
Please refer to the instructions of function
code F7.26, F7.27
Frequency 1 reaches
output value
Please refer to the instructions of function
code F7.28, F7.29
Frequency 2 reaches
output value
Please refer to the instructions of function
code F7.30, F7.31
Current 1 reaches
output value
Please refer to the instructions of function
code F7.36., F7.37
Current 2 reaches
output value
Please refer to the instructions of function
code F7.38, F7.39
Timer reaches output
value
Outputs ON signal when timer(F7.42)is
active and after the inverter's current running
time reaches the set time.
Outputs ON signal when the analog input
AI1 value is greater than F7.51 (AI1 input
protection upper limit) or less than F7.50 (AI1
input protection limit)
Outputs ON signal when the inverter is in
the load drop status.
Outputs ON signal when the inverter is in
the reverse running status.
Please refer to the instructions of function
code F7.32, F7.33
Module temperature
arrival
Outputs ON signal when the inverter
module radiator temperature(F6.06)reaches the
set temperature(F7.40).
Please refer to the instructions of function
code F7.34, F7.35
Lower limit frequency
arrival(stop with output)
Outputs ON signal when the operating
frequency reaches the lower limit frequency
Outputs ON signal too when the inverter is in
the sate of stop
