Chapter 5 Function parameter
115
Frequency source
main set
Maximum output
frequency of high-speed
pulse
SPB terminal is selected as pulse output, the function code is used to select the
maximum value of output pulse.
SPB switching quantity
output delay time
Relay 1 output delay time
Expansion DO output
delay time
Relay 2 output delay time
Set the delay time from occurrence to Actual output for output terminal SPA, SPB, relay
1, relay 2 and expansion DO.
DO output terminal
active status selection
SPB switching
quantity active
status selection
Relay 1 terminal
active status
setting (0 to 1,
as above)
Expansion D0
terminal active
status setting (0
to 1, as above)
SPA terminal
active status
setting (0 to 1,
as above)
Relay 2 terminal
active status
setting (0 to 1,
as above)
To define the output logic for output terminal SPA, SPB, relay 1, relay 2 and expansion
DO .0: positive logic：It is active status when the digital output terminal is connected with
the corresponding common terminal, inactive when disconnected; 1: anti-logic：It is inactive
