Chapter 5 Function parameter
128
0
1
2
3
4
5
6
7
8
910
11
121314
15
DI input situation
Bus voltage
(V)
Setting frequency
DO output situation
AI1 voltage
AI2 voltage
(Hz)
Count value
Remain
Length
Load speed
PID setting
(V)
(V)
PLC range
High speed pulse
input frequency
(Hz)
Remain
Remain
Remain
If the above parameters need to be displayed on operation, firstly set its position to 1,
and then set at F6.03 after converting the binary number to the hexadecimal number.
Load speed display coefficient
When load speed needs to be displayed, adjust the inverter's output frequency and load
speed by using the parameter.
Decimal places for load speed
display
Decimal places for load speed display The below example illustrates the calculation of
load speed:
If the load speed coefficient(F6.04) is 2.000, the number of decimal places of load
speed(F6.05) is 2 (two decimal places), when the inverter operating frequency reaches
40.00Hz, the load speed is : 40.00 * 2.000 = 80.00 (2 decimal places display)
If the inverter is shutdown, the load speed displays the speed relative to the set
frequency, that is the "set load speed". If the set frequency is 50.00Hz, the load speed under
the state of shutdown: 50.00 * 2.000 = 100.00 (2 decimal places display)
Inverter module radiator
temperature
Display the inverter module IGBT temperature
The different models of the inverter module vary IGBT overtemperature protection
values.
Display the total run time of inverter When the run time reaches the set time(F7.21), the
inverter's multi-function digital output function (12) outputs ON signal.
Display the total power consumption of inverter to date until now
