3Standard Service and Diagnostics Menus
About
There are three Standardized Service and Diagnostics menus used across Precor cardio
product lines providing equipment usage information, club settings, and machine service dia-
gnostic tests:
l Hardware Validation (5,1,7,6,5,7,6,1) is a set of automated diagnostic tests and hard-
ware calibration routines used to troubleshoot and verify machine operation.
l Club Settings (5,6,5,1,5,6,5) also referred to as Club Parameters used to manage and
customize user machine workout limit parameters. On touchscreen consoles, machine
usage information and error event code data is included.
l Information Display (6,5) provides software information, machine usage information,
and error event codes. Only supported on P10, P20, and P30 consoles.
The service and diagnostics menus are accessed by entering the standardized service access
code. The user interface and service menu capabilities will vary based on the console model
and type of exercise equipment. consoles that currently support standardized service modes
include:
Non-touchscreen consoles: P10, P20, and P30
Touchscreen consoles: P62, P80, and P82
Service Access Codes
The following table lists the available standardized service menus and access codes:.
SERVICE
ACCESS CODE SERVICE MENU FUNCTION
5,1,7,6,5,7,6,1 Hardware Validation Diagnostic tests.
5,6,5,1,5,6,5 Club Settings Configure machine and workout
parameter limits
(1)
.
6,5
‡
Information Display View usage stats, HW/SW con-
nectivity, and error code inform-
ation
(2)
.
1) On P62, P80, and P82 consoles, the Information Display (6,5) data is also included in Club Set-
tings (5,6,5,1,5,6,5).
2) The Information Display (65) is not supported on the P62, P80, and P82 consoles, access Club
Setting (5,1,7,6,5,7,6,1) to access similar data.
Experience Series 800 Line EFX
13
3 Standard Service and Diagnostics Menus
