Tools
General set of service and repair tools.
l US and Metric Hex Key set l Standard and Phillips screw driver set
l US SAE and Metric Wrench setl DVM Multimeter
l Torque wrench l External Retaining Ring Pliers
l US SAE and Metric socket set l Belt Tension Gauge (recommended Kent-Moore BT-33-73-F)
Specification Summary Table
This table provides a summary of system component torque and belt rating specifications.
System Component Specification
RF coax connector 2.4 in-lbs (0.271 Nm)
Display fasteners 180 in-lbs (20 Nm
Set screws 300 in-lbs (34 Nm)
Experience Series 800 Line EFX
5
1 Introduction
General Information
