Procedure
Review entire procedure before starting.
Removal Instructions
1. Remove the drive access cover, see "Drive Access Cover Replacement" on page56.
2. Remove the right and left drive disk covers, see "Drive Disk Covers Replacement" on
page57.
3. Remove the right Stairarm, see "Stairarm Replacement" on page117.
4. Use a 1/2" socket to loosen the two Drive Components Assembly fastener nuts (left
side)enough to allow movement. Do not remove the fastener nuts.
5. Use a 1/2" socket to loosen first stage belt tension and walk the first stage drive belt off
the pulleys. Remove the first stage drive belt.
Experience Series 800 Line EFX
68
5 Replacement Procedures
First Stage Drive Belt Replacement
