Lift Interface Plate Cover Replacement
Lift Interface Plate Cover Replacement
ID Description
Goose Neck Gasket
Goose Neck Cover
Top Lift Cover
Front Lift Cover
Lift Interface Plate Cover
Removal Instructions
1.
Remove the goose neck gasket , goose neck cover , top lift cover , and front
lift cover, see "Front Lift Cover Replacement" on page49.
2.
Remove the two #2 Phillips screw fasteners and remove the lift interface plate cover
. Retain fastener hardware for installation.
Installation Instructions
Experience Series 800 Line EFX
51
5 Replacement Procedures
Covers and Panels Replacement
