Precor Experience Series 800 line EFX User Manual

Removal Instructions
2. Use a nylon tipped screwdriver (or similar plastic device) to unsnap the goose neck
cover and gasket from the top of the front lift cover . Carefully insert the nylon
tip of the screwdriver at the front center between the goose neck cover and front lift
cover seam, While inserting the nylon tip apply pressure to unsnap the goose neck
cover and gasket in an upward direction. Remove the goose neck gasket and cover.
CAUTION:Only use plastic tipped screwdrivers (or similar devices) to unsnap the
goose neck cover Metal tipped devices will scratch the surfaces and damage the cov-
ers.
3.
Use your fingers to unsnap and lift the top lift cover from the top of the front lift cover
and accessory tray cover tabs.
4.
Use your fingers to unsnap and lift the front lift cover from the side cover tabs to
remove.
Installation Instructions
1.
Position the bottom of the front lift cover onto bottom front of the EFX base and
press into tabs. Then position the top cover onto the side cover tabs and press to lock in
place.
2.
Use your fingers to position the top lift cover onto the accessory tray and front lift
cover .tabs and press to lock in place.
3.
Use your fingers to position the goose neck cover onto the front lift cover tabs
and press to lock in place.
4.
Reinstall the goose neck gasket onto the display mount post and press into position
onto the top of goose neck flange opening.
Experience Series 800 Line EFX
50
5 Replacement Procedures
Covers and Panels Replacement
