DIAGNOSTIC
TEST
TEST DESCRIPTION
ACTIVE STATUS
LIGHT
The current ASL
1
status light state (blue. pulsing blue, yellow, & pulsing yel-
low).
AS LIGHT
BRIGHTNESS
Sets the ASL light brightness level and ON/OFF state:HIGH. MED, LOW,
and ON/OFF.
RPM TEST
(EFX only) Menu path: MACHINE TEST > RPM TEST
The current RPM (revolutions per Minute) value. The SPM (strides per
minute) is equal to 2 X RPM.
CROSSRAMP
TEST
Menu path: MACHINE TEST > CROSSRAMP TEST
(EFX, AMT Only)
Allows lift command operation during an active lift error condition (E40, E42,
E45, E46) even if the lift is out of range, jammed, or otherwise disabled due
to an error condition.
CAUTION: DO NOT jam the crossramp while operating in error mode -
There are no software position limit stops in this mode.
BATTERY TEST
Menu path: MACHINE TEST > BATTERY TEST
(EFX 800 only)
Shows the current battery voltage level as " XX.X VDC Y.".,
Where:
XX>X, measured DC battery voltage, nominal 12.6 - 14.6 Vdc.
Y suffix definition: "C": external AC charger is connected, "L" battery is low
(less than 11.5 Vdc), "CL" charger is connected and the battery is low.
P62, P80, and P82 consoles
Menu path:Hardware Validation Tests (5,1,7,6,5,7,6,1) > System Settings > System
Tests.
On P62, P80, and P82 consoles, the diagnostic tests are located in the Hardware Validation
System Tests menu.
SYSTEM TESTS TEST DESCRIPTION
Brake Test If brake is operational, provides the following information:
l PWRB XXX Displays the current power bits.
l VBUS XX Bus Voltage used to drive the brake.
l M-AMPS XX DC current going through brake.
Battery Test (EFX 800 only)
Shows the current battery voltage level as " XX.X VDC Y.".,
Where:
XX>X, measured DC battery voltage, nominal 12.6 - 14.6 Vdc.
1
Active Status Light: Service and maintenance status light.
Experience Series 800 Line EFX
19
3 Standard Service and Diagnostics Menus
Hardware Validation Service Menu (51765761)
