Moving Arms Replacement
About
This procedure provides instruction to remove and install the Moving Arms.
Specifications
System Component
Specification
Link Arm Fastener
300 +/- 90 in-lbs (34 +/- 10 Nm)
Procedure
Review entire procedure before starting.
Removal Instructions
Repeat this procedure for both the right and left Moving Arms.
1. Remove the Top Lift cover, see "Front Lift Cover Replacement" on page49.
2. Remove the #2 fastener and the Moving Arm - Outer Linkarm cover.
Experience Series 800 Line EFX
114
5 Replacement Procedures
Moving Arms Replacement
