SYSTEM TESTS TEST DESCRIPTION
Y suffix definition: "C": external AC charger is connected, "L" battery is low
(less than 11.5 Vdc), "CL" charger is connected and the battery is low.
SPM Test (EFX only)
Current SPM "Strides per Minute" value.
CrossRamp Test
(EFX, AMT only)
Manually run the lift motor to raise/lower the crossramp through full range,
levels 1 to 20.
Provides the lift potentiometer A/D digital value.
USB
1
Test
List the active USB ports.
Touchscreen
Test
Verify touchscreen operation.
Touchscreen Cal-
ibration
Calibrates touchscreen finger press operation.
Backlight Test
Tests the display backlight performance.
RGB Test
Tests the display color performance.
Numeric Backlight
Test
Tests the LED numeric display backlight brightness level.
Numeric Display
Test
Tests the LED numeric display.
Heart Rate Tests the handlebar unfiltered, filtered, and pulse heart rate. Grasp the grips to
test the hand held heart rate. Use a Polar heart rate simulator to test the wire-
less heart rate. Press the back button to exit this test.
Club Settings Service Menu (5651565)
Club Settings access code: 5,6,5,1,5,6,5 (see "Service Access Codes" on page13)
On non-touchscreen consoles (P10, P20, and P30), Club Settings is used to manage and cus-
tomize workout limit parameters. On touchscreen consoles (P62, P80, and P82), Club Set-
tings menu provides access to four main submenus: the About menu, the Equipment Usage
menu, the System Settings menu, and the Maintenance menu.
P10 & P30 consoles
The Club Settings menu is used to configure and customize workout parameters.
Menu path: Club Settings (5,1,7,6,5,7,6,1) > DIAGS - CLUB SETTINGS
1
Short for Universal Serial Bus, is an industry standard developed in the mid-1990s that
defines the cables, connectors and communications profocols used in a bus for connection,
communication, and power supply between computers and electronic devices.
