Precor S3.55 User Manual

S3.55 Assembly and Maintenance Guide
page 4
Table of Contents
4
13. Attach the Press Arm Cables to the Main Frame .......................................................... 21
14. Attach the Press Arm Pulleys to Main Frame ............................................................... 22
15. Feed the Row Arm Cable.............................................................................................. 23
16. Attach the Cable to the Row Arm .................................................................................. 25
Open Box 4 ............................................................................................................................. 27
17. Attach the Rear Shroud ............................................................................................... 28
18. Assemble the Weight Stack .......................................................................................... 29
19. Assemble the Top Cap Weight and the Selector Stem.................................................. 31
20. Assemble the Weight Stack Top Frame and Attach the Side Beam .............................. 32
21. Install the Add-On Weights ........................................................................................... 33
22. Remove the Pec Fly Drum Assembly from the Main Upright ........................................ 35
23. Install the Weight Stack Cable ...................................................................................... 36
24. Attach the Cable to the Main Frame ............................................................................. 38
25. Attach the Cable to the Leg Station .............................................................................. 41
26. Attach the Leg Station Cable to the Main Frame .......................................................... 43
27. Re-Install the Pec Fly Drum Assembly on the Main Upright ......................................... 44
28. Attach the Cables to the Pec Fly Drums ....................................................................... 45
29. Feed the Pec Fly Cable................................................................................................. 46
30. Attach the Shrouds ....................................................................................................... 47
31. Attach the Pec Fly Arms ............................................................................................... 49
32. Attach the Padded Seats .............................................................................................. 50
33. Install the Roller Pads and Attach the Accessories ...................................................... 51
34. Apply the Weight Decals ............................................................................................... 53
Adjustments and Maintenance ..................................................................... 54
1. Lat Pull and Seated Row Cable (46007-102) Adjustment ................................................... 55
2. Press Arm Cable (46008-101) Adjustment .......................................................................... 56
3. Press Arm Cable (46254-101) and Seat Carriage (46414-101) Adjustments ..................... 57
4. Pec Fly Adjustments ............................................................................................................ 59
5. Maintenance ........................................................................................................................ 60
Warranty Registration Card ..................................................................................................... 61
Precor Residential Equipment Limited Warranty ..................................................................... 63
Specifications ........................................................................................................... Back Cover

Precor S3.55 Specifications

Weight and Dimensions

length	86 inch (218 cm)
width	68 inch (173 cm)
height	82 inch (203 cm)
shipping weight	812 lb (370 kg)
