Precor S3.55 - Position Main Frame

S3.55 Assembly and Maintenance Guide
page 8
1 2 3 4 5 6
1. Position the Main Frame
A. Have an assistant help you lift the Main Frame out
of the packaging and place it flat on the floor near
the location where you plan to use it.
B. Grasp one side of the Main Frame and have your
assistant hold on to the other side. Tip the Main
Frame onto its base.
C. Use wire cutters to cut the tie wrap that secured
the Guide Rod Bracket during shipping.
Step 1. Position the Main Frame
B
A
Main Frame
Base of
Main Frame
C
Guide
Rod
Bracket
