S3.55 Assembly and Maintenance Guide
page 35
1 2 3 4 5 6
22. Remove the Pec Fly Drum
Assembly from the Main
Upright
Important: Before performing the following steps,
place the Press Arm assembly in a horizontal position.
Press the orange Release Lever on the left Press Arm
and lift up.
A. Cut the wire tie that secured the drums during
shipping.
CAUTION: The Pec Fly Drum Assembly is
heavy! Do not drop it! Ask for help! Obtain
adult assistance before removing the Pec Fly
Drum Assembly. If you don’t, you can inflict
injury to yourself or damage to the equipment.
B. Carefully remove the fasteners from the Main
Upright.
C. Set the Pec Fly Drum Assembly and fasteners
aside.
Step 22. Remove the Pec Fly Drum Assembly from the Main Upright
A
B
Pec Fly
Drum
Assembly
Main
Upright
C

Precor S3.55 Specifications

Weight and Dimensions

length	86 inch (218 cm)
width	68 inch (173 cm)
height	82 inch (203 cm)
shipping weight	812 lb (370 kg)
