S3.55 Assembly and Maintenance Guide
page 52
1 2 3 4 5 6
Step 33. Install the Roller Pads and Attach the Accessories, Continued
E. Attach a Spring Clip to the end of the Ab Crunch
Strap. Attach the Ab Crunch Strap to Cable
46007-102 in front of the Press Arms.
F. Attach a Spring Clip to Cable 46002-101 at the
base of the Weight Stack Side Beam.
G. Clip the Tricep/Bicep Straight Bar onto the Spring
Clip.
H, Place the Hand Weights on the Weight Rack.
E
F
G
Tricep/Bicep Straight Bar
Weight Stack Side Beam
Ab Crunch Strap
Cable 46002-101
H
Weight Rack
Hand Weights

Precor S3.55 Specifications

Weight and Dimensions

length	86 inch (218 cm)
width	68 inch (173 cm)
height	82 inch (203 cm)
shipping weight	812 lb (370 kg)
