97
9 Master Control
9.6 Scenes and Projects
StudioLive™ Series III
Owner’s Manual
Their parameters will be set as follows:
Fat Channel Parameters
CHANNEL HIPASS NOISE GATE LIMIT COMPRESSOR EQ LOW L.MID H.MID HIGH
GAIN 0db OFF STATE OFF STATE OFF THRESH 0 dB STATE OFF OFF OFF OFF
PAN <C> RANGE N/A RAT 2:1 P/S PEAK n/a n/a PEAK
Source Analog ATK 5 ms ATK 20 ms Q 0.6 0.6 0.6 0.6
REL 0.7 ms REL 150 ms FREQ 130 Hz 320 Hz 1.4 kHz 5 kHz
Key Src Off GAIN 0 dB GAIN 0 dB 0 dB 0 dB 0 dB
Key Fltr Off MODE Standard MODE Standard
Mode Expand
Power User Tip: Before beginning any new mixing situation, we recommended you reset
your scene. This is the easiest way to ensure that there are no lingering parameter settings
that could cause you some trouble in your new mix.
9.6.7 Nulling Parameters
To return any Fat Channel parameter to its default setting, simply press and hold
the Shift button and turn its encoder.
For example, if you want to null the current setting for the Channel 1 pan:
1. Select Channel 1.
2. Press and hold the Shift button.
3. Simultaneously turn Encoder 7: Compressor Threshold in the Fat Channel.
The compressor threshold for Channel 1 will return to its default setting.
Power User Tip: Parameters on 32-channel StudioLive Series III models can also
be nulled by holding the TAP button.
Select
GEQ
Mute
AUX
Inputs
DCA
Groups
Mix/FX
Master
Talk
NextPrev
Solo
Mute
Select
Solo
Mute
Select
Solo
Mute
Select
Solo
Mute
Select
Solo
Mute
Select
Inputs
User
Main
Mix
NextPrev
Solo
Mute
Select
Solo
Mute
Select
Solo
Mute
Select
Solo
Mute
Select
1 17 18
19 20
21 22
3
5
2
4
6
23 247 8
Select
GEQ
Mute
AUX
Inputs
DCA
Groups
Mix/FX
Master
Talk
NextPrev
Solo
Mute
Select
Solo
Mute
Select
Solo
Mute
Select
Solo
Mute
Select
Solo
Mute
Select
GAT E
Thresh
-84.00 dB
Gate
COMP
Thresh
0.00 dB
Comp
HI PAS S
Filter
52 Hz
EQ
Gain
0.00 dB
EQ
Freq
1.42 kHz
