3 Hookup
3.1 Rear Panel Configurations
StudioLive™ Series III
Owner’s Manual
3 Hookup
3.1 Rear Panel Configurations
3.1.1 StudioLive 64S
Analog Inputs
Mic / Line Mic Only Aux Inputs Tape Inputs Talkback In
32 Combo n/a 4 1/4” TRS 2 RCA 1 XLR (F)
Analog Outputs
Flex Mix Subgroup Main Out Mono / Center Monitor Out Tape Out
16 XLR (M) n/a 2 XLR (M) 1 XLR (M) 2 1/4” TRS 2 RCA
3.1.2 StudioLive 32S
Analog Inputs
Mic / Line Mic Only Aux Inputs Tape Inputs Talkback In
16 Combo 16 XLR 4 1/4” TRS 2 RCA 1 XLR (F)
Analog Outputs
Flex Mix Subgroup Main Out Mono Sum Monitor Out Tape Out
12 XLR (M)
4 1/4” TRS
4 1/4” TRS 2 XLR (M) 1 XLR (M) 2 1/4” TRS 2 RCA
