9 Master Control
9.1 StudioLive Series III FLEX DSP Rack Effects
StudioLive™ Series III
Owner’s Manual
If you have just one effects slot occupied by a delay effect, this button will set its
tempo. If you have more than one delay effect active, you must choose which delay is
governed by this button by pressing the Tap Assign button in the Effects Editor for
the desired delay.
StudioLive mixer models that are equipped with User Function buttons can dedicate
one or more of these buttons to act as a Tap Tempo control for any delay loaded. For
more information on User Function buttons, see Section 12.1.2.
9.1.1 The Effects Editor
As previously mentioned, tapping on any of the slots in the Effects Rack will launch
the Effects Editor. At the top of this screen, you will find the Effects Type drop-down
menu. Tapping on this menu will allow you select from the following effects:
• Digital XL Reverb
• PAE-16 Digital Reverb
• 335 Digital Reverb
• Vintage Plate Reverb
• Mono Delay
• Stereo Delay
• Ping Pong Delay
• Chorus
• Flanger
1. FX Slot. Displays the currently selected FX Slot.
2. Effects Type Menu. This drop-down menu allows you to change the active effect
currently selected FX Slot.
3. Presets. Opens the FX preset screen. See Section 9.1.3 for more information.
4. Current Parameter. Displays the parameter currently controlled by the Value
Encoder below the Touch Display, as well as its setting.
9.1.2 Effects Types
9.1.2.1 Digital XL Reverb
This convolution-style reverb emulates an acoustic space to add life and vibrancy and
provides the following controls:
• Predelay. Sets the length of short delay before the onset of reverberation, lending
a sense of space to the reflections.
• Reflection. This control allows you to set the level (in decibels) of the early
reflections. The louder the early reflections, the smaller the room will seem.
