19. Just like for the first instance of the RM CAN-Device Monitor software, create a new
generator with the following parameters:
Name Entry
Generator Name Generator CLwII
ID 124
Data Type UInt8
First Data Byte to generate Byte 1
Choose Generator Triangle, Cyclic, Cycletime 10
Generator CLwII parameters
20. Just like for the first instance of the RM CAN-Device Monitor software, create a new
indicator with the following parameters:
Name Entry
Indicator Name Indicator CLwI
ID 123
Data Type UInt8
First Data Byte to trigger Byte 1
Choose Indicator Graph
Indicator CLwI parameters
21. In the GENERATOR CLWII window, click the SEND button.
 This starts the G
ENERATOR CLWII.
22. Switch to the first instance of RM CAN-Device Monitor.
23. In the G
ENERATOR CLWI window, click the SEND button.
 This starts the G
ENERATOR CLWI.
