Device Manual CANlink wireless
Functionality and features
PROEMION GmbH | Phone: +49 661 9490-600 | Fax: +49 661 9490-666 | info@proemion.com | proemion.com | Version 1.0 27
© 2016RM MICHAELIDES● VX.X ● Device Manual CANlink 5000 series © 2016RM MICHAELIDES● VX.X ● Device Manual CANlink 5000 series © 2016 PROEMION GMBH > 1.0 EN > Device Manual CANlink wireless 3000 series
3.3 Indicator element (LED)
The front of the device features a two-color LED for indicating function and status.
INFORMATION
The two-color LED features the colors red and green. When both colors are simultaneously
active, the LED lights up orange.
The following table shows possible statuses of the indicator LED:
