ProMinent gamma XL User Manual

1608
Liquid end, self-degassing SER 1096251
Spare parts kit 1047831
Diaphragm 1030353
1608
Liquid end with degassing 1096252
Spare parts kit 1083565
Diaphragm 1030353
1
5
1
8
6
2
7
P_G_0109_SW
40351206
2
3
4
Fig. 48: Liquid end of gamma/ XL 1612 - 0730 PV_2
Tab. 39: Spare parts for liquid end gamma/ XL 1612 - 0730 PV_2
Pos. Designation
1 Connector kit
5 Discharge valve
6 Diaphragm
8 Suction valve
Liquid end gamma/ XL PVT 7, SER
Liquid end gamma/ XL PVF2, FDA
Liquid end 1612 - 0730 PV_2
Exploded drawings of the gamma/ XL
127
