1612 1020 0730
Liquid end without degassing 1096284 1096285 1096262
Spare parts kit 1030525 1030526 1030612
Diaphragm 1000248 1000249 1045456
1
5
1
8
6
2
7
P_G_0109_SW
40351206
2
3
4
Fig. 47: Liquid end of gamma/ XL 1608 PV_2
Tab. 38: Spare parts for liquid end gamma/ XL 1608 PV_2
Pos. Designation
1 Connector kit
5 Discharge valve
6 Diaphragm
8 Suction valve
1608
Liquid end with degassing 1096265
Spare parts kit 1030225
Diaphragm 1030353
Liquid end gamma/ XL NPB 0
Liquid end 1608 PV_2
Liquid end gamma/ XL PVT 2
Exploded drawings of the gamma/ XL
126
