RLX2 Industrial Hotspot Series
Page 146 of 212 ProSoft Technology, Inc.
June 15, 2015
Master; always shown at the top
Radio linked to the network
Radio not linked; no parent
An Ethernet connection exists to the radio; does not indicate
the number of devices on the connection
Wireless clients (PCMCIA cards) are linked to this radio; the
number of clients linked is indicated by the number of boxes
Signal strength; the width of the line is not calibrated
Alternate parents.
