ProSoft Technology RadioLinx RLX2-IHW User Manual

RLX2 Industrial Hotspot Series
Page 60 of 212 ProSoft Technology, Inc.
June 15, 2015
Diagnostics
The Radio Configuration / Diagnostic Utility (Web configuration form for the radio)
provides information that can help troubleshoot problems with the radio.
Use the program’s diagnostic and signal strength settings at the top of the Radio
Settings window to make sure the network is working properly.
Signal Strength graph: This setting graphically shows the radio’s signal strength.
 The graph will show the word Master if a master radio is selected.
 The graph will show the word Scanning if the radio is scanning to find another radio
to which to connect.
 If the radio is not connected to a network and not currently scanning, the graph will
show the words Not Connected.
 If the radio is configured as a Repeater and has linked to a Master, the Signal
Strength graph will show a color-coded signal quality indication.
Update every: To update the diagnostic readings according to a particular time interval,
specify the interval (in seconds) in this field. After entering the new value, press Enter to
save the new value. Press Tab or click elsewhere to use the new value temporarily.
The following configuration forms in the Radio Configuration / Diagnostic Utility provide
information about current radio operation:
 Address table (page 75)
 Port status (page 76)
 Available Parents
 Read-only fields (page 72)
The following topics describe troubleshooting routines:
 Check the Ethernet cable (page 61)
 Retrieve the default password (page 63)
 Troubleshoot IH Browser error messages (page 65)
 Troubleshoot missing radios in the IH Browser (page 65)
For more troubleshooting information, visit the ProSoft Technology website at
www.prosoft-technology.com.
