RLX2 Industrial Hotspot Series

ProSoft Technology, Inc. Page 173 of 212

June 15, 2015

Ethernet Cable Configuration (all other radios)

Straight-Though Cable

RJ-45 Pin

1 Rx+

1 Tx+

2 Rx-

2 Tx-

3 Tx+

3 Rx+

6 Tx-

6 Rx-

Crossover Cable

RJ-45 Pin

1 Rx+

3 Tx+

2 Rx-

6 Tx-

3 Tx+

1 Rx+

6 Tx-

2 Rx-
