5. The equipment shall be properly grounded with the external ground screw provided
connected to building ground as well as the antenna coaxial screen of the connector shall be
grounded.
6. Device must be powered by a Class 2 Power Source.
7. The common or earth side of the circuit side is connected to the screen of the coaxial cable
and to all accessible parts and circuits.
8. Shall be installed in Restricted Access Location Only.
9. Antennas are to be installed in accordance with Control Drawing 06/2514. You can find the
Control Drawing in the Antenna section of this manual.
Recommended Antennas
ProSoft offers a variety of Antennas and Cables for use with your RadioLinx device. The following is
a sample of available antennas.
For a complete list and description, please visit our website: http://www.prosoft-
technology.com/Products/Industrial-Wireless - Antennas and Accessories.
3 dBi Omni N-BH jack whipless 2.4GHz
4 dBi Omni N BH jack low profile 2.4GHz
4 dBi Omni N jack collinear with mounting hardware 2.4GHz
5 dBi Omni RP-SMA articulating 2.4GHz
5 dBi Omni RP-SMA straight w/magnetic base 2.4GHz
5 dBi Omni RP-SMA straight 2.4GHz
6 dBi Omni N jack collinear with mounting hardware 2.4GHz
6dBi Omni N jack heavy duty collinear with mounting hardware 2.4GHz
6dBi Panel RP-SMA MIMO antenna with 3 foot pigtail 2.4GHz
8 dBi Directional patch panel N jack with mounting hardware 2.4GHz
8 dBi Omni N jack collinear with mounting hardware 2.4GHz
9 dBi Omni N jack heavy duty collinear with mounting hardware 2.4GHz
10 dBi Directional N jack Yagi with mounting hardware 2.4GHz
10 dBi Omni N jack collinear for marine environment, 2.4GHz
