ProSoft Technology RadioLinx RLX2-IHW User Manual

RLX2 Industrial Hotspot Series
Page 188 of 212 ProSoft Technology, Inc.
June 15, 2015
Approved Antenna Table
Use the following approved antennas when the radio module is connected directly to an
antenna. Refer to Approved antennas with power amp for a table of approved antennas
with bi-directional power amplifiers.
Type
Pattern
Gain
Connector
Size (cm)
Min. distance
from Body
1/2 Wave
Omni
2 dB
SMA-RP
7H x 1.5
20 cm
1/2 Wave art.
Omni
2 dB
SMA-RP
10H x 1.0
20 cm
Collinear Array
Omni
3 dB
SMA-RP
6H x 3.0
20 cm
Collinear Array, art.
Omni
5 dB
SMA-RP
19H x 1.0
20 cm
Collinear Array
Omni
5 dB
SMA-RP
19H x 1.0
20 cm
Collinear Array
Omni
8 dB
N-RP
43H x 1.6
20 cm
Collinear Array
Omni
9 dB
N-RP
43H x 1.6
20 cm
Collinear Array
Omni
12 dB
N-RP
106H x 4.0
25 cm
Patch
Directional
8 dB
SMA-RP
15.0H x 15.0
20 cm
Patch
Directional
11 dB
SMA-RP
22H x 12.7
22 cm
Patch
Directional
13 dB
N-RP
22H x 22
28 cm
Patch*
Directional
19 dB
N-RP
15.5 x 15.5
57 cm
Yagi
Directional
14 dB
N-RP
81L x 9.0
28 cm
Parabolic*
Directional
15 dB
N-RP
40H x 51W x 25D
36 cm
Parabolic*
Directional
19 dB
N-RP
58H x 66W x 26D
57 cm
Parabolic*
Directional
24 dB
N-RP
78H x 96W x 29D
100 cm
* Only allowed in a point-to-point network.
Approved Antennas in Europe/CE
The gain of the antenna connected to the main antenna port, minus the antenna cable
loss, must be less than 4 dB to stay below the 100-mW EIRP transmit power limit.
The AUX port is only used to receive; it never transmits.
Note: In France, the user is responsible for ensuring that the selected frequency channels comply
with French regulatory standards. At the time of this printing, only channels 10 through 13 can be
used in France.
