ProSoft Technology RadioLinx RLX2-IHW User Manual

RLX2 Industrial Hotspot Series
ProSoft Technology, Inc. Page 177 of 212
June 15, 2015
Frequency Band
Frequency
Channel
Wireless Standards
802.11n, 802.11a, 802.11g,
802.11h (DFS), 802.11i (Security), 802.11e (QoS), 802.1Q (VLAN),
802.3af (PoE) IGMPv2
Transmit Power
(Programmable)
*Subject to Regional
Regulatory Limits
22 dBm @ MCS0, MCS8 (802.11a/g/n)
17 dBm @ MCS7, MCS15 (802.11a/g/n)
22 dBm @ 6 Mbps (802.11a/g)
17 dBm @ 54 Mbps (802.11a/g)
Antenna Impact:
3 Antennas/ MIMO: Use values above
2 Antennas: Subtract 3 dB from values above
1 Antenna: Subtract 5 dB from values above
Channel data rates
(802.11n)
MCS0 through MCS15,
1 Channel or 2 Channels with 1 Stream or 2 Streams
1 Channel
2 Channels
Rate
Streams
6.5 Mbps
15 Mbps
MCS0
1 Stream
65 Mbps
150 Mbps
MCS7
13 Mbps
30 Mbps
MCS8
2 Streams
130 Mbps
300 Mbps
MCS15
Channel data rates
(802.11a/b/g)
802.11a/b/g:
54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2.1 Mbps
Receiver Sensitivity
(Typical)
-92 dBm @ MCS0, MCS8 (802.11an/gn)
-70 dBm @ MCS7, MCS15 (802.11an)
-74 dBm @ MCS7, MCS15 (802.11gn)
-92 dBm @ 6 Mbps (802.11an/gn)
-74 dBm @ 54 Mbps (802.11a)
-78 dBm @ 54 Mbps (802.11g)
Security
WPA2 Enterprise – 802.11i AES w/RADIUS [PEAP, TTLS, TLS, EAP]
WPA2 Personal – 802.11i AES w/Passphrase
Legacy WPA TKIP, WEP support
MAC ID filter
Physical
Enclosure
Extruded aluminum with DIN rail mount (RLX2-IHNF)
Die-cast Aluminum with Pole Mount (RLX2-IHNF-W and RLX2-
IHNF-WC)
Size
14.8 x 11.8 x 3.8 cm (H x W x D) (RLX2-IHNF)
5.82 x 4.64 x 1.48 in (H x W x D)
29.2 x 17.8 x 7 cm (H x W x D) (RLX2-IHNF-W and WC)
11.5 x 7 x 2.75 in (H x W x D)
Shock
IEC 60068 2-6 (20g, 3-Axis)
Vibration
IEC 60068 2-27 (5g, 10Hz to 150Hz)
