ProSoft Technology RLX2-IHA - RLX2-IHA Detailed Specifications

RLX2 Series ♦802.11a, b, g, n Reference
Industrial Hotspots User Manual
ProSoft Technology, Inc. Page 127 of 161
May 8, 2013
8.6 RLX2-IHA Detailed Specifications
Radio
Frequency Band
(Varies by country)
802.11a
5.150 GHz to 5.250 GHz (FCC/ETSI)
5.725 GHz to 5.850 GHz (FCC)
Wireless Standards
802.11a, 802.11i
Transmit Power (Programmable)
(varies by country)
24 dBm (250 mW) @ 6 Mbps
24 dBm (250 mW) @ 24 Mbps
21 dBm (125 mW) @ 54 Mbps
Channel data rates (Modulation)
802.11a: 54, 48, 36, 24, 18, 12, 9, 6 Mbps (OFDM)
Receiver Sensitivity (Typical)
-92 dBm @ 6 Mbps
-84 dBm @ 24 Mbps
-72 dBm @ 54 Mbps
Channel Selection
36, 40, 44, 48, 149, 153, 157, 161, 165
Security
WPA2 - 802.11i with 128 bit AES-CCM
Legacy WPA TKIP, WEP support
MAC ID filter
Admin password
Physical
Enclosure
Extruded aluminum with DIN and panel mount
Size
14.8 x 11.8 x 3.8 cm (H x W x D)
5.82 x 4.64 x 1.48 in (H x W x D)
Shock
IEC 60068 2-6 (20g, 3-Axis)
Vibration
IEC 60068 2-27 (5g, 10Hz to 150Hz)
Ethernet Ports
One 10/100/1000 Base-T connector, shielded RJ45
Antenna Port
(1) RP-SMA connector
Weight
1.1 lbs (499g)
Environmental
Operating Temperature
-40°C to +75°C (-40°F to +167°F)
Humidity
Up to 100% RH, with no condensation
External Power
PoE Injector
Power over Ethernet
10 Vdc to 24 Vdc
48 Vdc
802.3af Compliant
Average Power
Less than 7 Watts
Agency Approvals & Certifications
Wireless Approvals
Visit www.prosoft-technology.com for current wireless approval information.
Hazardous Locations
Regulatory
UL/cUL; Class1, Div 2
CSA/CB Safety
Ex Certificate (ATEX Directive, Zone 2)
CE Mark
FCC/IC
ETSI
